What is the ERS Registry?

The ERS Registry is a modified fork of the ENS Registry used to manage ERS names. ERS names provide a way to track the chain of custody of chips from manufacturer to Developer to Project to end-user, in this way the ERSRegistry contract acts as an easy way to validate the authenticity of items that contain embedded chips enrolled in the ERS system.

Each name is associated with a Record that points towards an owner and resolver address. The owner address is the address that can add subdomains to a given name. In some instances the owner is also allowed to set a new owner of the Record. However, once set the resolver parameter of a Record cannot be updated, it is forever tied to the address / chip that was specified upon Record creation. We do this to make sure that the chain of custody of a chip cannot be altered after the fact (thus breaking authentication of chips).

How is the ERS Registry updated?

As mentioned above the ERS Registry can only be updated by the owner of a given Record. The most common update will be adding subnodes for a given name. Subnodes can be added in the following ways...

Creating Developer Subnodes

The root of each name is the .ers node which is owned by the DeveloperRegistry. Since the DeveloperRegistry owns the .ers domain it can create new subdomains for each Developer that joins the system, thus making [Developer].ers names. New Developer subnodes are created when a Developer calls createDeveloperRegistrar on the DeveloperRegistry, the resulting DeveloperRegistrar address is set as the owner and resolver.

Creating Project Subnodes

DeveloperRegistars are required to be trusted contracts of the system because they must correctly add project subdomains to the Developers domains. This creates subdomains of the structure, [project].developer.ers. Similarly the project subdomain is created by calling addProject on the DeveloperRegistrar which sets the passed ProjectRegistrar as the owner and resolver of the subdomain.

Creating Chip Subnodes

ProjectRegistrars set subnodes for each chip enrolled in the project via the addChip process. The big difference from other nodes is that chip subnodes have the chipId set as the resolver address, where for chip subnodes the ServicesRegistry is set as the resolver address. Additionally, the owner address can be updated as part of a transfer call to the ChipRegistry, in this way the chain of custody is still preserved even when chip ownership is transferred.

Additional Permissions

In addition to the permissions described above the ERSRegistry also has a few other permissioned functions that are used to manage the system:

1. The Developer subnodes can be clawed back by the DeveloperRegistry via the deleteSubnodeRecord function. In this instance the history of projects and chips under the Developer is still maintained but the Developer can no longer add new projects or chips.
2. The ChipRegistry has the ability to update the owner parameter of chip subnodes via the setNodeOwner function. This is used to maintain state when chips are transferred from one owner to another. Note that node owners still maintain the ability to transfer ownership of chips this just builds allows the ChipRegistry to be able to transfer on behalf of an owner during transfer.
